Thông số kỹ thuật
| PROCESSOR | Supports 9th/8th Gen Intel® Core™ / Pentium® Gold / Celeron® processors for LGA 1151 socket |
| CHIPSET | Intel® B365 Chipset |
| MEMORY | 4x DDR4 memory slots, support up to 64GB Supports DDR4 2666/ 2400/ 2133 MHz Supports Dual-Channel mode Supports non-ECC, un-buffered memory Supports Intel® Extreme Memory Profile (XMP) Please refer to Compatibility for more information on compatible memory |
| SLOTS | 1 x PCIe 3.0 x16 slot 2 x PCIe 3.0 x1 slots |
| ONBOARD GRAPHICS | 1 x VGA port, supports a maximum resolution of 2048×1536@50Hz, 2048×1280@60Hz, 1920×1200@60Hz 1 x DVI-D port, supports a maximum resolution of 1920×1200@60Hz 1 x HDMI™ port 1.4, supports a maximum resolution of 4096×2160@30Hz |
| STORAGE | Intel® B365 Chipset 6 x SATA 6Gb/s ports1 1 x M.2 slot (Key M)Supports up to PCIe 3.0 x4 and SATA 6Gb/s Supports 2242/ 2260 /2280/ 22110 storage devices Intel® Optane™ Memory Ready2 The SATA1 connector will be unavailable when an M.2 SATA SSD module has been installed in the M.2_1 slot. Before using Intel® Optane™ memory modules, please ensure that you have updated the drivers and BIOS to the latest version from MSI website. |
| RAID | Intel® B365 Chipset Supports RAID 0, RAID1, RAID 5 and RAID 10 for SATA storage devices |
| USB | Intel® B365 Chipset 8 x USB 3.1 Gen1 (SuperSpeed USB) ports (3 Type-A & 1 Type-C ports on the back panel, 4 ports available through the internal USB connectors) 6 x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB connectors) |
| AUDIO | Realtek® ALC892 Codec 7.1-Channel High Definition Audio |
| LAN | 1 x Realtek RTL8111H Gigabit LAN controller |
| INTERNAL CONNECTORS | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 6 x SATA 6Gb/s connectors 2 x USB 3.1 Gen1 connector (supports additional 4 USB 3.1 Gen1 ports) 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 1 x 4-pin CPU fan connector 2 x 4-pin system fan connectors 1 x Front panel audio connector 1 x Parallel port connector 1 x Serial port connector 2 x Front panel connectors 1 x TPM module connector 1 x 4-pin RGB LED connector 1 x Chassis Intrusion connector 1 x Clear CMOS jumper |
| BACK PANEL PORTS | Mouse Port VGA Port HDMI Port LAN Port USB 3.1 Gen1 USB 3.1 Gen1 Type A Keyboard Port DVI-D Port USB 2.0 Ports USB 3.1 Gen1 Type C HD Audio Connectors |
| DIMENSIONS | 9.6 in. x 9.6 in. (24.4 cm x 24.4 cm) Micro-ATX Form Factor |
| MOUNTING | 8 mounting holes |
| OPERATING SYSTEM | Support for Windows® 10 64-bit |
